Model：EKDX008VS1~EKDX240VS1

Cooling capacity：25~642KW

Condensing heat recovery capacity：18~225KW

Refrigerant：R410A

1. High efficiency and energy saving, the energy saving rate can reach 70%

2. Minimum 5℃ ultra low dew point depth dehumidification

3. High precision control, temperature ±1℃, humidity ± 5%

4. Intelligent adaptive operation

5. A variety of high strength, high sealing box optional

6. Full DC inverter ODU

7. EK-cloud platform, factory cloud service

Model：EKRT150A1～EKRT420A1

Cooling capacity：43.5～118KW

Air flow：8000～21300m3/h

Refrigerant：R401A

1. The unit is placed directly outside, and the unit shell is resistant to corrosion and has strong adaptability

2. The unit features an integral structure design and factory assembly, making it safe, reliable, and energy-efficient

3. The unit adopts microcomputer controller, which makes the operation stable and reliable

4. The unit can be installed in various outdoor places without special equipment room, flexible installation and space saving

Model：EKDX008VR1~EKDX210VR1

Cooling capacity：25~595KW

Heating capacity：28~615KW

Refrigerant：R410A

1. The same patented box structure as the combined air handling unit

2. Modular design, the load can be multi-stage adjustment, but also variable frequency stepless adjustment

3. Simple system, no water system, no freezing risk, easy maintenance

4. Save land, no need for the host special equipment room, the internal machine can be placed outside

5. Wide operating range, the minimum can be -15℃ low temperature refrigeration, -30℃ ultra-low temperature heating
